Jinli compression springs CO., LTD.

● Product Introduction

Wire Diameter: 5mm ~ 60mm

Materials:

Hard Drawn Wire SWC

SUP9 and SUP Series

SAE9254

Stainless Steel SUS-304/316

Music Wire SWP-A/B

Oil Tempered Carbon Steel Wire SWOSC-B

● Product Features and Applications

Absorb Vibration

Accumulate and release energy to absorb vibration

Buffer Impact force

Utilize elasticity to return to original position and shape

Since compression springs are frequently used in various industries, design issues are often encountered. The main source of spring pressure is composed of wire diameter, inner and outer diameter, and effective number of coils, and the resulting force can be obtained by calculating the K value. Therefore, understanding some basic principles can help better understand design needs. Our company can help customers recalculate or provide better recommendations based on sufficient materials for wire diameters from 5mm to 60mm. Please provide detailed specifications and drawings for further discussion.
